BAUM 714XLT Ultrafold Tabletop Folder 2nd Station
Compact 8-Page Right-Angle, Cross-fold, Booklet Folder Machine
The Baumfolder 2nd station is a versatile folding solution that operates as a standalone unit or pairs seamlessly with the 714XLT folder. It can handle letter folds, fan folds, double parallel folds, and single folds. Folds can be bypassed, and it can be used as a perf or score machine. In line with the 714, it creates 8-page signatures and enables right-angle folding to produce newsletters, brochures, and other documents sized for postal regulations or envelope insertion in a single pass. The flow-thru design features innovative pivoting idler rolls that eliminate gap setting requirements and easy access slitter shafts.
Much needed equipment for the instruction and pharmaceutical market.
Watch the BAUM 714XLT. This folder can be a standalone unit or operated in line with a 714 8-page tabletop folder.
Technical Specifications
- Maximum sheet size parallel: 14” x 12.5”
- Minimum sheet size: 3” x 5”
- Maximum size fold – #1 or #2 plate: 13.5”
- Minimum size fold: 2.25”
- Minimum paper weight: 14 lb cover
- Maximum paper weight: 75 lb cover
- Parallel fold roll speed: infinitely variable
- Operating voltage: 110 VAC – 60 Hz
- Amperage: 20 amp
- Type folder: right angle up & down
- Machine dimensions: 85”L x 38”W x 41”H
- Weight 2nd station (crated): 490 lbs
- Slitter shaft: fixed
- Stand comes standard
- Optional sound covers
Key Features
- Made in the USA with a robust design backed by over 100 years of folder manufacturing expertise
- Optional sound covers
- Configurable for right-angle folding or tandem operation for multiple parallel folds
- Up and down fold plates for expanded imposition options
- Positive drive timing belt cross-carrier roller design
- Loads and unloads the same end of the machine
- 3-year or 6,000-hour warranty on parts
- Toner-resistant and static-dissipative polyurethane folding rollers
- Sealed ball bearings require no lubrication
- Gear-driven folding rollers prevent slippage during folding
- Automatic roller tensioning for consistent performance
- Includes a fixed-height cart as standard equipment
- Built to last for long-term reliability and low total
cost of ownership
